| Parameters |
| Traction type: 6x4 |
| Chassis:North Benz |
| Cabin:V3 with A/C |
| Engine brand: Weichai |
| Model: 290hp--375hp |
| Displacement: 9.726 or 11.596L |
| Engine output: 336Hp @2200 rpm |
| Max. torque: 1250 NM @1200-1600rpm |
| Bore:126mm |
| Stroke:150mm |
| Specific fuel consumption: 198g/kwh |
| Transmission (gear box): FAST 9 speeds |
| Clutch:D430 Diaphragm type |
| Steering:TAS85 |
| Front axle: BENZ front axle |
| Rear axle: BENZ strengthened driving axle |
| Fuel tank: 300L |
| Tire: 12.00R20 Radial tire |
| No.tyre: 10+1 spare |
| Rim:8.5-20 |
| Max. speed (km/h): 85 |
| Kerb. mass: 9100kg |
| Total mass: 25000g |
| Wheel base (mm): 3800+1450 |
| Front overhang (mm): 1410 |
| Rear overhang (mm): 2055 |
| Approach angle: 24degree |
| Departure angle: 29degree |
| Dimension (mm):8825×2495×3260 |
| Body(mixer,drum): |
| Capacity:7--12 CBM |
| Water Tank: 400L |
| Discharged remain ratio:<0.5% |
| Hydraulic pump and motor :EATON (AMERICA) |
| Decelerator:BONFIGLIOLI Decelerator |
| Features: |
| Crank chute operation |
| High pressure water jets, with air pressure supply |
| Rod manipulation |
| Radiator made in China |
